Fluid Bed Processor
(FBP).
Granulate, dry & coat — without leaving the bowl.
Dryer / Processor
Overview
Engineered for repeatability.
FBPs combine fluid-bed drying with top-spray, bottom-spray (Wurster) or tangential-spray for granulation & coating — all in a single contained bowl, eliminating transfer steps.
Construction & Specs
Specifications
What's standard. What's optional.
| Charge size | 15 · 30 · 60 · 120 · 250 kg |
| MOC | SS 316L · SS 304 cladding |
| Spray | Top · bottom (Wurster) · tangential |
| Nozzles | Single & multi-nozzle configurations |
| PLC | Full recipe management |
| Cleaning | WIP / CIP nozzles |
| Compliance | GMP · cGMP · ATEX (option) |
- Three operations in one machine — granulation, drying, coating
- Eliminates batch transfer between machines
- Wurster column for pellet coating
- Recipe-driven PLC for repeatability
- Integrated explosion-vent option
Applications
Where they go to work.
Rx
Modified release
Pellet coating for sustained-release dosage.
Nu
Coating
Vitamin & herbal pellet coating.
Sd
Spheronisation prep
Pellet build-up for spheronisation.
