Multi Mill
(MM).
Wet, dry, fine, coarse — one mill, every duty.
Mill
Overview
Engineered for repeatability.
Multi Mills handle wet & dry milling, granulation breaking and size reduction in a single compact unit. Reversible swing-beater configuration gives flexibility to switch between forward and reverse rotation.
Construction & Specs
Specifications
What's standard. What's optional.
| Capacities | 5 kg/hr · 25 kg/hr · 50 kg/hr · 100 kg/hr · 250 kg/hr |
| MOC | SS 316L / 304 · removable beater set |
| Beater configurations | Knife · impact · reversible swing |
| Screens | 0.5 mm to 12 mm — quick-change |
| Drive | Direct-drive motor · 2880 rpm typical |
| Finish | GMP polished |
| Compliance | GMP · cGMP |
- Reversible rotation — forward for impact, reverse for knife
- Quick screen change · no tools
- Compact footprint
- Hopper & collection bin included
- Mobile trolley mounting option
Applications
Where they go to work.
Wt
Wet milling
Wet granule break-down post-RMG.
Dr
Dry milling
Lump-breaking of caked APIs.
Ch
Chemical
Crystalline size reduction.
